ECM
ECM Serial

Description: This machine is suitable for applying the emulsion coating with high precision on large printing frame.

Features:

Entire machine is operated automatically. High quality and precision screen can be produced without the requirement of skillful technical personnel.

Loading/unloading of the printing frame is controlled by the foot switches, facilitating the operator to hold the printing frame properly during the loading/unloading process.

The emulsion thickness is controlled by adjusting the coating pressure and the number of coating.

Option for single sided or simultaneously double-sided coating, the number of coating is set individually.

The coating speed is stepless adjustable.

At the final phase of coating process with a distance of 20 mm, the coating speed will automatically changed into creeping motion in order to scope off any excessive emulsion from the screen to prevent any possible dripping, no retouch is required.

The coating trough is specially manufactured, the evenness of coating is guaranteed by the absolute straightness of trough edge.

Removable drip tray is provided for maintaining the cleaning of the machine.

The buzzer is automatically activated after the coating cycle is completed, operator is not required during the coating process.

Model
ECM-1212
ECM-2035
Max .frame size
1200×1200mm
2000×3500mm
Max .coating size
1100×1050mm
1900×3350mm
Applicable web depth
20-40mm
20~40mm
Presetting coating time
1-99次
1~99次
Coating speed
0~90mm/s
0~90mm/s
Manifold air pressure
0.5MPa
0.5MPa
Electricity
2P 220v/0.5kw
2P 220v/ 0.6kw
